I-PAD CU-SP1

Semi-automatic defibrillator specifically designed for the non-medical personnel.

I-Pad Cu- Sp1 is able to automatically adjust its volume in proportion to the noise of the environment.
The defibrillator I-PAD CU- SP1 is able to detect if it has been effected or not the CPR maneuver. If you have not already done so, it invites the operator to proceed, otherwise, it encourages the operator to continue, guiding him through the operation.
I-PAD CU- SP1 captures and automatically analyzes the patient's electrocardiogram to detect the presence of a rhythm and, in the event of a cardiac arrest, leads the operator through the rescue process with voice prompts and graphical indicators. If a shockable rhythm is detected, the device will automatically charge and defibrillation shock is emitted when the operator presses the SHOCK button.
Cu-Sp1 has pre-connected plates housed in a special compartment underneath the defibrillator. This gives the assurance that the defibrillator is ready to use as soon as possible. The device is also provided with a unique technology able to make a precise control on the state of life of the plates. The front of the defibrillator, in fact, has an indicator light that changes color both three months before the expiry of the plates and with plates expired. This indication, on time, will allow the change of plates in time.
Downloading information from the defibrillator I-Pad Cu- Sp1, after an event, it is now easier than ever. Simply install the software CU-EX1 on a computer in order to view and analyze the use that was made of the defibrillator. The device can also store up to 5 events with up to 3 hours of ECG analysis on an SD card. In this case, the data can be transferred by removing the SD card from the defibrillator or via the infrared port.

Standard equipment:
- Defibrillator
- Plates
- Battery
- User Manual
